Torq/Gard TG060 Taper Grip Clutch
Torq/Gard TG060 Taper Grip Clutch
Regular price
$1,888.00 USD
Regular price
Sale price
$1,888.00 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
The Taper Grip Bushing (TGBU) is a tapered bushing that fits in the finished tapered bore, creating a final bore size of 3/4", 1", or 1.125" based on the model. This enables a more adaptable shaft-mounting solution. The bore presses around the shaft as the bushing is tightened and expands inward.
The Torq/Gard TG60-TGBU is a torque-limiting power transmission overload clutch. The modular design accommodates direct drive, chain drive or other power transmission options and the universal mounting eliminates the need for special bore requirements.
Max Bore Size: 3/4, 1, or 1.125 inches
Trip Torque Range: 200 - 600 in-lbs
Max Power: 8.5 hp
Max Speed: 900 rpm
Weight: 5.5 lbs
Inertia: 10 lb-in2
The Torq/Gard TG60-TGBU is a torque-limiting power transmission overload clutch. The modular design accommodates direct drive, chain drive or other power transmission options and the universal mounting eliminates the need for special bore requirements.
Max Bore Size: 3/4, 1, or 1.125 inches
Trip Torque Range: 200 - 600 in-lbs
Max Power: 8.5 hp
Max Speed: 900 rpm
Weight: 5.5 lbs
Inertia: 10 lb-in2
